Engineering Plastic Fasteners
Nylon Fasteners and PCB Hardware
Sucatec supplies nylon fasteners, insulating hardware and PCB support components for electronics manufacturing, semiconductor equipment, cleanroom assembly and industrial applications requiring lightweight, corrosion-resistant and electrically insulating fastening solutions.
Available product groups include circuit board supports, spacers, washers, screws, nuts, rivets, cable management products and engineering plastic hardware manufactured in PA66, UL94V-2 and UL94V-0 materials.
PCB Hardware
Spacers & PCB Supports
Adhesive Base Spacers
Push-in circuit board spacers with integrated acrylic or rubber adhesive tape base. PA66 UL94V2/V0. Heights 4.8–28.6 mm. 84 part numbers.
PCB MountingRound Nylon Spacers
Cylindrical round nylon spacers in PA6+GF, PA66, HIPS and PVDF. OD range 4–18 mm. Natural, black and white. 87 part numbers.
PCB MountingSpecial Spacers
Cupped, teardrop, push-through, wire-base, edge-holding, stacking and card guide spacers for specialist PCB mounting. 458 part numbers.
Insulating Hardware
Washers & Caps
Nylon Washers
Retaining, anti-loss, distance, shoulder and screw-insulator washers in PA66, PA6 and PVC. Natural, black and white. 79 part numbers.
Insulating HardwareFinishing Washers & Protection Caps
Finishing (beauty) washers and snap-on protection caps for screw and bolt heads. PA66 UL94V2, natural and black. 41 part numbers.
Plastic Fasteners
Screws & Nuts
Slotted Cheese Head Screws
Slotted drive cheese head nylon screws. PA66 UL94V2. Metric threads M2–M8, lengths 3–50 mm. 122 part numbers.
Nylon ScrewsCountersunk, Pan & Hex Head Screws
Slotted and cross-recessed countersunk, raised countersunk, pan head and hex head nylon screws. M2–M8. 537 part numbers.
Screws & NutsPush-In Screws & Nylon Nuts
Knurled thumb screws, push-in panel screws and KWIK hex nuts in PA66. M2–M8. Anti-twist and lockable variants. 260 part numbers.
Plastic Fasteners
Rivets & Panel Fasteners
Rivets & Panel Fasteners
Snap rivets, push rivets, clinch rivets, drive fasteners, mounting buttons and snap latches. PA6, PA66 and PA46. 687 part numbers.
Panel FastenersBarbed & Push-Fit Fasteners
Pawl-lock barbed push fasteners and arrowhead-locking push-fit panel fasteners in PA66 and PA6. Panels 0.5–8 mm. 121 part numbers.
Panel FastenersSpecial Fasteners & Fixings
Push rivets, drive fasteners, removable rivets, hole plugs, mini barbed rivets and quick-lock nut holders. 75 part numbers.
Panel FastenersTwist Lock & Quarter-Turn Fasteners
Twist lock (Kurly Lock), stand-off twist locks, adhesive-base and fir-tree variants. Panel thickness 0.5–8 mm. 297 part numbers.
Cable Management
Cable Management
Cable Ties
Reversed, blind-hole mount, push-mount, tie-on and rivet-mount nylon cable ties. PA66 UL94V2, black and natural. 34 part numbers.
Cable ManagementCable Tie Holders
Adhesive base, push-mount and screw-in cable tie holders and flat tie holders. PA66 UL94V2. Cable ties up to 9 mm wide. 55 part numbers.
Cable ManagementCable Clamps
Screw-mount, adhesive-base, stand-off, plug-in and hinged-locking cable clamps and harness clips. Cable Ø 3–30 mm. 262 part numbers.
Wire SaddlesWire Saddles — Arrowhead & Locking
Arrowhead push-in, micro locking, standard locking, side-entry, wide and quarter-turn locking wire saddles. PA66 UL94V2. 276 part numbers.
Wire SaddlesWire Saddles — Edge Holding & Adhesive
Blind-hole mount, edge-holding, side-mount, adhesive-base and micro adhesive-base wire saddles. PA66 UL94V2. 42 part numbers.
Specialist Components
Specialist Hardware
Bushings, Bearings & Grommets
Open and closed nylon bushings, plate bearings, vibration grommets, push-in plugs and hole plugs. PA66, POM and rubber. 35 part numbers.
PCB & LightingLED Hardware
LED spacers type 1, 2 and 3, square LED spacers and high-temperature metric LED spacers for standard and high-power LEDs. 128 part numbers.
Motion ControlRotary Dampers
Oil-filled rotary dampers with gear drive. PC/POM construction. Torque ratings 25–180 gf.cm. Controlled resistance for doors, lids and rotating assemblies. 41 part numbers.
Typical Materials
| Material | Description | Typical Use |
|---|---|---|
| PA66 Nylon | General engineering thermoplastic with good strength and electrical insulation properties. | PCB supports, spacers and general fastening. |
| UL94V-2 Nylon | Flammability-rated nylon for electronics assembly environments. | Electrical and electronic hardware. |
| UL94V-0 Nylon | Higher flame-retardant material for critical electronic assemblies. | Semiconductor and electronics equipment. |
| PA6 / PA46 | Engineering nylons offering good impact strength and toughness. | Rivets, panel fasteners and clips. |
| POM (Acetal) | High stiffness, low friction engineering plastic with excellent dimensional stability. | Bushings, bearings and precision components. |
| PC (Polycarbonate) | Tough, impact-resistant transparent engineering thermoplastic. | Rotary dampers and optical-path components. |
Applications
PCB and Electronics Assembly
Nylon PCB supports, spacers and insulating hardware used across electronics assembly and control panel manufacturing.
Semiconductor Equipment
Lightweight, clean and corrosion-resistant plastic fasteners used in semiconductor and controlled manufacturing equipment.
Electrical Insulation
Insulating washers, shoulder washers and nylon hardware for electrical separation and low-conductivity applications.
Cleanroom Equipment
Plastic fasteners and spacers suitable for selected cleanroom manufacturing and contamination-sensitive assemblies.
Need nylon fasteners or PCB hardware?
Contact Sucatec for nylon screws, PCB supports, spacers, insulating washers, engineering plastic hardware and specialist fastening solutions.
